Main Specifications

• Operating Frequency: Ku-band
• Operating System: Integrates DBF technology and multi-phase center angle measurement technology
• Scanning Coverage: 360°
• Range: 5 km
• Detection Range:
  ≥3 km (Personnel)
  ≥5 km (Small Vehicles)
• Detection Accuracy:
  Range: ≤3 m
  Azimuth: ≤0.4°
• Communication Interface: Gigabit Ethernet (Aviation Connector)
• Weight: ≤14 kg (main unit only)
• Data Update Interval: 0.25 s
• Simultaneous Tracking Targets: ≥400 batches
• Radial Velocity Detection Range: 0.4~60 m/s
• Clutter Rejection Capability: No false alarms caused by common clutter
• Power Consumption: ≤120 W
• Power Supply Range: DC 18~28V (with AC220V to DC24V adapter)
• Environmental Adaptability: Operating Temperature: -40~+55°C, IP67 Protection Rating
• Main Unit Dimensions: 340×320×350 mm
